The High-gravity rectification system represents the core component of modern process intensification technology in separation systems. This innovative equipment utilizes centrifugal force to create a high-gravity environment where mass transfer efficiency is dramatically enhanced. The rotating bed design enables extremely high separation efficiency in a remarkably compact form factor, typically achieving in just 1 meter what conventional packed towers require 10-15 meters to accomplish. Our HGD beds are engineered for precision separation of complex mixtures, offering unprecedented performance in chemical processing, pharmaceutical manufacturing, and environmental applications.
| Model | DN300 | DN550 | DN700 | DN950 | DN1150 | DN1350 | |
| Dealing Capacity(kg/h) | 500-100 | 100-400 | 300-700 | 600-1000 | 900-1500 | 1200-2200 | |
| Power(kw) | 1.5-2.2 | 5.5-7.5 | 11-15 | 15-18.5 | 22-30 | 37-45 | |
| Overall Size(mm) | L | 450 | 1200 | 1400 | 1800 | 2100 | 2400 |
| W | 450 | 700 | 1000 | 1250 | 1500 | 1800 | |
| H | 1500 | 1900 | 2200 | 2400 | 2500 | 2800 | |
Rotating Packed Bed Technology: Patented structured packing designs optimized for centrifugal operation
Precision Control Systems: Optimization of rotation speed, temperature, and flow rates
Energy Integration: Heat pump integration and multi-effect thermal coupling
Zero-Leakage Design: Magnetic drive systems and advanced sealing technology
●Lower height, smaller size, suitable for space limited occasions, saving investment and maintenance costs;
●Higher separation efficiency, more stable performance and lower energy consumption than traditional column type distillation equipment;
●Reduce production labor intensity and improve production safety.
Pharmaceutical Industry: Antibiotic purification, solvent recovery, chiral separatio
Fine Chemicals: High-purity specialty chemicals, isomer separation
Environmental Engineering: VOC recovery, wastewater treatment, emission control
Energy Sector: Biofuel purification, carbon capture, hydrogen processing
Food & Beverage: Essential oil refinement, natural product extraction
Cosmetics: Fragrance purification, active ingredient concentration
Cutting-Edge Innovation: Incorporating latest research findings and patents
Reliability Engineered: Designed for 100,000+ hours of continuous operation
Cost Advantage: 50% lower capital cost, 60% reduced operating cost
Space Optimization: Ideal for brownfield expansions and mobile applications
Safety First: compliant designs for hazardous environments
Global Support: 24/7 technical support with remote diagnostics
Sustainability Leader: Reduced carbon footprint and waste generation
Custom Solutions: Tailored designs for specific process challenges
Widely used in methanol, ethanol, isopropyl alcohol, acetone, acetonitrile, tetrahydrofuran, dichloromethane, ethyl acetate, toluene and other organic solvents recovery and product separation & purification. It has been industrialized apply in chemical, pharmaceutical, environmental protection, biomedicine and other industries.
