Higee bed, widely used in methanol, ethanol, isopropyl alcohol, acetone, acetonitrile, tetrahydrofuran, dichloromethane, ethyl acetate, toluene and other organic solvents recovery and product separation & purification. It has been industrialized apply in chemical, pharmaceutical, environmental protection, biomedicine and other industries.
| Model | DN300 | DN550 | DN700 | DN950 | DN1150 | DN1350 | |
| Dealing Capacity(kg/h) | 50-100 | 100-400 | 300-700 | 600-1000 | 900-1500 | 1200-2200 | |
| Power(kw) | 1.5-2.2 | 5.5-7.5 | 11-15 | 15-18.5 | 22-30 | 37-45 | |
| Overall Size(mm) | L | 450 | 1200 | 1400 | 1800 | 2100 | 2400 |
| W | 450 | 700 | 1000 | 1250 | 1500 | 1800 | |
| H | 1500 | 1900 | 2200 | 2400 | 2500 | 2800 | |
Rotating Packed Bed Technology: Patented structured packing designs optimized for centrifugal operation
Precision Control Systems: Optimization of rotation speed, temperature, and flow rates
Energy Integration: Heat pump integration and multi-effect thermal coupling
Zero-Leakage Design: Magnetic drive systems and advanced sealing technology
●Lower height, smaller size, suitable for space limited occasions, saving investment and maintenance costs;
●Higher separation efficiency, more stable performance and lower energy consumption than traditional column type distillation equipment;
●Reduce production labor intensity and improve production safety.
Pharmaceutical Industry: Antibiotic purification, solvent recovery, chiral separatio
Fine Chemicals: High-purity specialty chemicals, isomer separation
Environmental Engineering: VOC recovery, wastewater treatment, emission control
Energy Sector: Biofuel purification, carbon capture, hydrogen processing
Food & Beverage: Essential oil refinement, natural product extraction
Cosmetics: Fragrance purification, active ingredient concentration
Cutting-Edge Innovation: Incorporating latest research findings and patents
Reliability Engineered: Designed for 100,000+ hours of continuous operation
Cost Advantage: 50% lower capital cost, 60% reduced operating cost
Space Optimization: Ideal for brownfield expansions and mobile applications
Safety First: compliant designs for hazardous environments
Global Support: 24/7 technical support with remote diagnostics
Sustainability Leader: Reduced carbon footprint and waste generation
Custom Solutions: Tailored designs for specific process challenges
Higee bed represents the core component of modern process intensification technology in separation systems. This innovative equipment utilizes centrifugal force to create a high-gravity environment where mass transfer efficiency is dramatically enhanced. The rotating bed design enables extremely high separation efficiency in a remarkably compact form factor, typically achieving in just 1 meter what conventional packed towers require 10-15 meters to accomplish. Our HGD beds are engineered for precision separation of complex mixtures, offering unprecedented performance in chemical processing, pharmaceutical manufacturing, and environmental applications.
This system’s closed, compact design reduces solvent exposure, enhancing operator safety. Its rapid start-up and shut-down capability align perfectly with batch production modes, while its superior separation efficiency ensures maximum solvent recovery, reducing both raw material costs and waste disposal volumes.
The adoption of our higee bed technology over conventional packed or tray distillation columns is driven by several transformative advantages:
Dramatically Smaller Footprint: Our high gravity rectification system utilize high-speed rotation to generate a super gravity field, intensifying mass transfer by orders of magnitude. This allows a unit the size of a desk to replace a traditional column several stories tall, saving invaluable floor space.
Exceptional Energy Efficiency: The intensified mass transfer and high separation efficiency lead to significantly lower energy consumption for the same throughput. Reduced boiling temperatures further decrease steam or heating utility demands, slashing operational costs.
Superior Product Quality & Flexibility: Extremely short liquid residence time (measured in seconds) within the rotor minimizes the risk of thermal degradation or polymerization for sensitive materials. This is paramount for pharmaceuticals, nutraceuticals, and fine chemicals. The systems also offer quick start-up and easy changeover between different products.
Reduced Capital & Operating Costs: The compact size translates to lower material and installation costs. Minimal holdup volume means less waste during product changeovers. Easier maintenance and automated control further contribute to a lower total cost of ownership.
Enhanced Safety & Environmental Profile: The sealed, compact design with a small liquid inventory presents a lower inherent risk. Higher recovery rates of solvents reduce VOC emissions and waste generation, supporting greener manufacturing goals.
Higee bed cases link: https://chinzmachine.com/alternatives-to-conventional-distillation-stripping-tower-higee-system/
